Sharp Advanced V801U-W

SHARP Combining Laser and LCD for brilliant colour and contrast wth cost concious installation & TCO. Features No lamp replacement – up to 20,000 h maintenance free operation possible due to Laser Light Source. Get Great Performance – while not compromising on quality and ease of use. Low Noise Level – with 31dB, the silent technology will not disturb your meeting. Impress with vivid colour & contrast – brilliant white and wide colour space with high dynamic contrast. Incredible visualisation capabilities – impressive free tilt and portrait installation capability, unique geometric adjustment, tiling and camera based blending. Specifications General Information Projection Technology: 3LCD Technology Native Resolution: 1920 x 1200 Aspect Ratio: 16:10 Contrast Ratio (typ.): 3,000,000:1 Brightness (Lumen): 8000 Lm Normal / 8300 Lm Center / 7200 Lm Silent Mode; compliant with ISO21118-2012 Light Source: Laser Light Source Life: 20,000 hrs Lens: 5 motorized lens options Lens Adjustment: Motorized Keystone Correction: +/- 30° manual horizontal / +/- 30° manual vertical Lens Shift: H: ±20, V: +10 / -50 Projection Factor: depending on lens selection (std. option XP‑41ZL at 1.3–3.02:1) Projection Distance (m): 0.7 – 50.9 Screen Size (diagonal): Max. 1,270 cm; Min. 101.6 cm Zoom: Motorized and manual (depending on lens) Focus Adjustment: Motorized and manual (depending on lens) Frequency: Digital Frequency — Horizontal: 15/24–153 kHz; Vertical: 24–120 Hz Connectivity Digital Input: 1 x HDBaseT; 2 x HDMI™ supporting HDCP Audio Input: 1 x HDBaseT audio support; 2 x HDMI audio support Audio Output: 1 x 3.5 mm Stereo Mini Jack Input Control: 1 x 3.5 mm Stereo Mini Jack (Wired Remote); 1 x D‑Sub 9 pin (RS‑232); Ethernet LAN: 1 x RJ45 USB: 1 x Type A (USB 2.0 high speed) Remote Control: Audio Control; Digital Zoom; Geometric Correction; HDMI; ID Select; ID Set; Keystone Correction; Picture Adjust; Picture Mute; Power; Shutter; Source Select; Test Picture; Wired/Wireless Connection; Zoom/Focus and Lens Shift Control Electrical Power Supply: 100–240 V AC; 50–60 Hz Power Consumption: 467W Normal / 421W Silent Mode / 2W Network Stand‑by / 0.5W Stand‑by Environmental Operating Temperature: 0ºC to 40ºC Operating Humidity: 20% to 80% Storage Temperature: -10ºC to 50ºC Storage Humidity: 20% to 80% Mechanical Dimensions (W x H x D) [mm]: 499 x 164 x 407 (without lens and feet) Weight [kg]: 11.2 Fan Noise [dB(A)]: 42 / 32 (Normal / Silent) Colour Versions: White Optional Accessories Optional Accessories: 5 optional bayonet lenses; Cable Cover (XP‑13CV‑W, XP‑13CV‑B) Lenses (Motorized): XP‑40ZL/NP40ZL (0.79–1.11:1); XP‑41ZL/NP41ZL (1.3–3.02:1); XP‑43ZL/NP43ZL (2.99–5.93:1); XP‑44ML‑A/NP44ML‑PA4 (0.32:1); XP‑50ZL/NP50ZL (0.6–0.75:1) Other Features Safety and Ergonomics: RCM; CE; EAC; ErP; RoHS Special Characteristics: AMX Beacon; Cinema Quality Picture (CQP) Processing; Control ID Function; Crestron RoomView; DICOM simulation; Direct Power‑Off; Edge Blending; Free Tilt; Geometric Correction; HDBaseT; High Altitude Mode; HTTP Browser Control; Keystone Correction (H=±30°, V=±30°); LAN control; Lens Memory; Lens Shift (vertical +0.5 max / -0.1 max, horizontal ±0.2 max); Light Source Adjustment; Manual Wall Color Correction; NaViSet Administrator 2; Optional User Logo; OSD with 27 languages; Password Security System; PJ LINK; Portrait Setting; Quick On/Off; RS‑232 Control; Test Pattern; Up to 20,000 hrs Light Source Life Shipping Content (Accessories): Power Cable; Projector; Quick Setup Guide; IR Remote Control
