Lindy 70M CAT6 IR Split Extend
SKU GT-023486 · MPN 38155 · GTIN 4002888381550
$531.95
Includes GST. Delivery calculated at checkout.
Out of stock
Payment options are shown at checkout.
Specifications
| Bulky Item | No |
|---|---|
| Dangerous Goods | No |
| Pack Quantity | 1 |
Description
Lindy 70m CAT6 4 Port HDMI & IR Splitter Extender Features An advanced Splitter Extender that extends and distributes HDMI & IR signals to 4 displays at distances of up to 70m Supports resolutions up to 3840x2160@30Hz 4:4:4 8bit, including FullHD Features a loop-through HDMI output on the transmitter for local monitoring/cascading Supports power over Cable (PoC), only a single power supply is required for operation 2 year warranty Specifications AV Interface AV Interface: HDMI Interface Standard: HDMI 1.4 Supported Bandwidth: 10.2Gbps Maximum Distance: 70m (229.66ft): 1920x1080@60Hz; 40m (131.23ft): 3840x2160@30Hz 4:4:4 8bit Maximum Resolution: 3840x2160@30Hz 4:4:4 8bit HDCP Support: HDCP 1.4 EDID Pass Through: Preset, Cloning Function Supported Audio: Up to 7.1 (Pass-through) IR Support: 20-60 kHz Transmission Medium: 1 x Cat.6 (per receiver) Special Features: PoC (Power over Cable) Connectors Transmitter Input: HDMI (Female) Transmitter Output: 4 x RJ45 (Female), HDMI (Female), IR (Female) Receiver Input: RJ45 (Female), IR (Female) Receiver Output: HDMI (Female) Bidirectional Ports: N/A Power: 5.5/2.1mm DC socket Physical Properties Dimensions WxHxD: Transmitter: 210x83x17mm (8.27x3.27x0.67in) Receivers: 79x68x17mm (3.11x2.68x0.67in) (per unit) Housing Material: Metal Net Weight: Transmitter: 0.443kg (0.98lb) Receiver: 0.131kg (0.29lb) per unit Operating Temperature: 0°C - 40°C (32°F - 104°F) Storage Temperature: -20°C - 60°C (-4°F - 140°F) Humidity: 20-90% RH (non-condensing) Power Requirements: 12VDC 2.5A Colour: Black Miscellaneous Packaging Type: Carton Box Packaging Dimensions: 310x162x74mm (12.21x6.38x2.91in) Gross Weight: 1.516kg (3.34lb) Warranty (Years): 2 Certified: CE, UKCA, FCC, RoHS, REACH
