CP Switched Ats 32AMP
SKU GT-021593 · MPN PDU44302 · GTIN 4711027799650
$2,434.95
Includes GST. Delivery calculated at checkout.
In stock
Payment options are shown at checkout.
Specifications
| Bulky Item | No |
|---|---|
| Dangerous Goods | No |
| Pack Quantity | 1 |
Description
CP Switched ATS 32Amp Phase: Single Phase Dual Power Inputs: Yes Nominal Input Voltage ( Vac ): 200 - 240 Input Frequency ( Hz ): 50 / 60 Maximum Input Current ( A ): 32 Input Connector Type: IEC 60309 32A x 2 Power Cord Length: 3.05m Output Voltage ( V ): Depends on Input Overload Protection: Circuit Breaker Over Current Protection (Each Bank) ( A ): 20 Outlets - # of Bank(s): 2 Outlet(s) - Total: 18 Outlet(s) - Rear: 18 Outlet Type: IEC C19 x 2 | IEC C13 x 16 Remote Individual Outlet Control: Yes LCD Information Display: Input Voltage (Volts) | Input Frequency (Hz) | Current Level (Amps) | Power Consumption (Kilowatts) | Network Information | Serial Number | Environment Status | Hardware Version | Firmware Version Hot-swappable LCD Module: Yes LCD Setting & Control: Preferred Source | Source Configuration | Load Configuration | Outlet Control | LCD Settings | Reset / Reboot LED Indicators: PDU Status | Source Status | Load | Tx/Rx | Link | Outlet A-type USB Port: Yes Connectivity Port: RJ45 | RJ45 (for Serial) | RJ45 (for ENVIROSENSOR/ Daisy Chain (In)) | RJ45 (for Daisy Chain (Out)) Environmental Sensor Supported: Yes User-upgradeable Firmware: Yes Power Management Software: PowerPanel Business (Recommended for small-medium scale management) | PowerPanel Enterprise (Recommended for large scale management) Supported Protocols: IPv4/v6 | SNMPv1/v3 | HTTP/HTTPs | TCP/IP | UDP | DHCP | NTP | DNS | SMTP | SSH | SSL | TLS | Telnet | FTP | and Syslog Authentication: RADIUS | LDAP | LDAPS | Windows AD Installed Rack Height (U): 2 Form Factor: 2U Horizontal Rackmount Enclosure Construction: Steel Cord Retention Tray: Yes IEC Receptacle Locking: Yes External Site Ground Pin: Yes Adjustable Mounting Brackets: 1 Set Dimensions: 433 x 88 x 215mm Weight: 7.8kg Certifications: CE | FCC Class A | UL62368 | EN 55032 Class A | IEC 62368 | RoHS
